S P E C I F I C A T I O N S
SYSTEM CAPACITY
- 16,384 Outputs/parameters
- 5,000 Control Channels
- 9,999,999 Presets
- 4 x 999 Palettes (Focus, Color, Beam, All)
- 999 Groups
- 999 Macros
- 999 Sequences
- 999 Master Pages
- 99 Effect Playbacks
- Supports three external DisplayPort monitors starting at 1280x1024 resolution with optional touchscreen control
- Solid-State Hard Disk
- Seven USB 2.0 ports for USB flashdrive, pointing devices, keyboards
INTERFACES
- Two individually configurable Ethernet ports, 802.3af compliant PoE
- ETCNet2, Net3 (powered by ACN), sACN and ArtNet output protocols
- Two DMX512A/RDM ports
- Contact closure triggers via D-Sub connector
- Three female IEC connectors
- Three video connectors support DisplayPort external displays (1280x1024 minimum resolution) with optional single- or multi-touch screen control
- USB 2.0 multipurpose (seven ports)
- Client PC via Ethernet (requires Client Dongle)
- Net3 Radio Focus Remote (RFR) via USB or Ethernet
- Phone Remote
- OSC Open Sound Control via Ethernet
- UDP event triggering via Ethernet
- aRFR for Android devices and iRFR for Apple iOS devices via wireless Ethernet
- MIDI in/out (MIDI timecode, MIDI notes, MIDI Show Control (MSC))
- MIDI timecode, MIDI Show Control through Net3 Show Control Gateway
- SMPTE timecode through Net3 Show Control Gateway
- Contact closure (12 analog inputs, 12 SPDT contact outputs, RS-232) through Net3 I/O Gateway
- Support for up to 60 additional master playbacks using Cobalt Motorized Fader Wings, Universal Fader Wings or the Congo jr™ Master Playback Wing
ELECTRICAL
- AC input (100 - 240V at 50/60 Hz)
- Maximum power consumption (excluding external monitors) approximately 2A 120/240V
PHYSICAL
Dimensions*
| MODEL |
HEIGHT |
WIDTH |
DEPTH |
| |
inches |
mm |
inches |
mm |
inches |
mm |
| Cobalt 10 |
12.5 |
318 |
31.9 |
811 |
23.5 |
597 |
Weights*
| MODEL |
WEIGHT |
SHIPPING WEIGHT |
| |
lbs |
kgs |
lbs |
kgs |
| Cobalt 10 |
55 |
24.9 |
63.5 |
28.8 |
*Weights and dimensions typical
ORDERING INFORMATION
Cobalt 10
| MODEL |
DESCRIPTION |
| CBLT 10-US |
Cobalt 10 Console, 4,096 Outputs, US Accessories |
| CBLT -LS-US |
Cobalt Light Server, 4,096 Outputs |
| ETCNOMAD |
Cobalt ETCnomad, 1,024 Outputs |
| CBLT 10 MAX |
Cobalt 10 Console, 16,384 Outputs |
| CBLT 10 Up |
Cobalt 10 Output Upgrade to 16,384 Outputs |
Cobalt 20 and Cobalt 10 are offered as a base console with 5000 control channels and 4,096 outputs (8 universes of DMX512A). A single control channel may control only intensity (dimmers) or it may control a DMX-controlled device (moving light, LED, media server, etc.).
To increase the capacity of the console to its maximum of 16,384 outputs, order the Cobalt Maximum Output upgrade.
Two universes are available at the console via 5-Pin XLR and all universes may be distributed via Ethernet-based methods, including Net3 DMX/RDM Gateways, ETCNet2 DMX Nodes and/or ArtNet nodes (purchased separately).
Cobalt Accessories
| MODEL |
DESCRIPTION |
| Cobalt MFW20 |
Cobalt Motorized Fader Wing 20 |
| Cobalt MFW10 |
Cobalt Motorized Fader Wing 10 |
| NET3 RFR |
ETC Net3 Radio Focus Remote |
| NET3-RFR-RX |
ETC Net3 Radio Focus Remote, receiver only |
| NET3-RFR-TX |
ETC Net3 Radio Focus Remote, transmitter only |
| CBLT Littlite |
Cobalt Littlite® Worklights (spare) |
| CBLT 10 Flightcase |
Cobalt Flightcase |
| NET3 RVI |
ETCNet3 Remote Video Interface |
| 19” LCD |
19” Flat-screen display (1280x1024) |
| 19”LCD-T |
19” Touchscreen display |
| WMON |
Wide-format flat-screen display |
| WMONTS |
Wide-format multi-touch display |
Cobalt Offline Editor software for Mac and PC platforms is available for download from
www.etcconnect.com
SHIP WITH:
- Power cord
- Dust cover
- Two Littlite® worklights
- Mouse and mousepad
- External alpha-numeric keyboard (US model only)
